Features:
- Hinged base adjusts to variable halyard and control line angles.
- Smooth Delrin ball bearing sheave
- Low profile design keeps control lines and halyards close to the deck
- Open ball bearing races are easy to maintain
- Tumbled and polished stainless steel frame
Specifications:
- Maximum Line Size: 7/16″ (11mm)
- Safe Working Load: 1,000lbs. (454kg)
- Sheave Diameter: 2″ (51mm)
- Length: 3-1/4″ (83mm)
- Width: 7/8″ (22mm)
- Height: 3-1/16″ (78mm)
- Bearing Height: 1-3/16″ (30mm)
- Fastener Centers: 2-1/8″ (54mm)
- Required Fasteners: 2 x 1/4″ (6mm) flat head
- Weight: 7.3oz. (207g)
