Plastimo 414549 – Anodised Aluminium Bow Roller with Locking Device 245 × 150 × 60 mm
The Plastimo 414549 Bow Roller is engineered to provide safe and reliable anchor handling while protecting both the anchor and the bow during deployment and recovery. Manufactured from corrosion-resistant anodised aluminium, it combines lightweight construction with excellent durability for long-term marine use.
An integrated locking device securely holds the anchor in position while underway, reducing movement and improving safety. Designed for anchors weighing between 8 and 12 kg, the bow roller offers smooth operation thanks to its precision roller and robust construction.
Key Features
- Marine-grade anodised aluminium construction
- Integrated locking device for secure anchor retention
- Designed for anchors weighing 8–12 kg
- Lightweight, corrosion-resistant construction
- Smooth anchor deployment and retrieval
- Suitable for permanent bow installation
- Ideal for sailing yachts and motorboats
Technical Specifications
| Article | 414549 |
| Product Type | Anodised Aluminium Bow Roller |
| Material | Anodised Aluminium |
| Overall Dimensions | 245 × 150 × 60 mm |
| Maximum Anchor Weight | 8–12 kg |
| Sheave Diameter | 70 × 30 mm |
| Dimension A | 10 mm |
| Dimension B | 45 mm |
| Dimension C | 242 mm |
| Dimension D | 150 mm |
| Dimension E | 42 mm |
| Dimension F | 58 mm |
Applications
- Secure storage of anchors while underway
- Smooth anchor deployment and recovery
- Bow-mounted anchoring systems
- Suitable for recreational and cruising boats
Brand: Plastimo
