MZ ELECTRONIC Universal Anchor Windlass Control Panel with LCD Chain Counter – Wired & Radio Versions, 12/24V
The MZ ELECTRONIC Universal Anchor Windlass Control Panel is designed to provide comprehensive monitoring and control of electric anchor windlass systems. Featuring an LCD display with backlit buttons, the panel delivers clear operating information while allowing convenient control of the windlass.
The display provides real-time information including chain length hauled in or paid out, chain speed, supply voltage, motor current draw, docking alarm status and total windlass operating hours. The system supports a maximum measurable chain length of 999 metres.
Available in both wired and radio versions, the control panel is compatible with 12V and 24V electrical systems. An optional magnetic sensor (02.355.00) can be added when required for chain counting functionality. The IP65-rated housing is suitable for marine installations.
Key Features
- Universal control panel for electric anchor windlasses;
- LCD display with backlit buttons;
- Displays chain length hauled in or paid out;
- Chain speed indication;
- Supply voltage display;
- Motor current draw indication;
- Docking alarm indication;
- Windlass operating hours display;
- Maximum measurable chain length: 999 m;
- Available in wired and radio versions;
- Optional magnetic sensor available;
- IP65 protection rating.
Technical Specifications
| Application | Electric anchor windlass control and chain counting |
| Operating Voltage | 12 / 24 V |
| Display | LCD with backlit buttons |
| Protection Rating | IP65 |
| Maximum Chain Length | 999 m |
| Optional Accessory | Magnetic sensor 02.355.00 (if required) |
| Dimensions | 100 × 100 × 32 mm |
Available Variants
| Code | Version | Operating Voltage | Maximum Chain Length |
|---|---|---|---|
| 02.356.03 | Cable connection to the windlass | 12 / 24 V | 999 m |
| 02.356.01 | Radio, no cables between windlass and console | 12 / 24 V | 999 m |
