The Maxwell RC6 Vertical Anchor Windlass is a high-performance anchoring solution designed for small metal vessels (4.5-6.5 meters) and plastic yachts (4.5-8 meters). Built from robust AISI316 stainless steel, this compact windlass is capable of handling up to 700 kg of static load with ease. It supports a 12 mm anchor cable or a 6/7 mm short anchor chain, ensuring versatility and efficiency for a wide range of boats. The RC6 is easy to install and guarantees long-term, trouble-free operation.
Key Features:
- Made of durable AISI316 stainless steel for corrosion resistance.
- Supports 6/7 mm anchor chain and 12 mm anchor cable.
- Maximum static thrust of up to 700 kg.
- Effortless installation with an inline gearbox and motor.
- Compact and sleek design, ideal for smaller vessels.
- Available in low-profile configuration.
- Equipped with Maxwell’s patented Wave Design™ technology for enhanced performance.
Specifications:
| Model | Traction | Static Load | Chain Lifting Speed | Cable Lifting Speed | Motor Power | Weight |
|---|---|---|---|---|---|---|
| Maxwell RC6 | 350 kg | 700 kg | 24 m/min | 21 m/min | 500 W | 8.5 kg |
Dimensions:
| A | B | C | D | E | F |
|---|---|---|---|---|---|
| 196 mm | 80 mm | 145 mm | 209 mm | 65 mm | 39 mm |
Important Notes:
- Use a chain stopper or other chain-fixing device to relieve load from the windlass when anchoring.
- Ensure the anchor chain is secured during vessel movement to prevent damage or accidents.
Standard Equipment: Circuit breaker (ordered separately), remote control (ordered separately), double relay (included), handle (supplied separately).
Maxwell RC6 Anchor Winch Selection Guide:
| Model | Light Vessel Length | Heavy Vessel Length | Chain Size | Cable Size |
|---|---|---|---|---|
| Maxwell RC6 | 4.5-8.5 m | 4.5-7.0 m | 6/7 mm | 12 mm |
Vetus Catalog Articles:
P102569, P102570
The Maxwell RC6 Vertical Anchor Windlass offers a reliable and efficient solution for safe anchoring on smaller vessels. Contact the Yacht Supply24 team for more details or assistance in selecting the right product for your needs.
