Maxwell Height Matched Stainless Steel Chain Stopper
The Maxwell Height Matched Chain Stopper is engineered to securely retain the anchor chain while transferring the anchoring load from the windlass to the deck structure. By eliminating continuous load on the windlass, it helps extend equipment life and improves anchoring safety.
This chain stopper is recommended whenever the vessel is riding at anchor, when breaking the anchor free from the seabed, or to prevent accidental free-fall of the anchor while underway. The Height Matched design is intended to align correctly with compatible Maxwell windlass installations for smooth chain handling and reliable locking performance.
Key Features
- Transfers anchoring loads away from the windlass.
- Secures the anchor chain while at anchor.
- Helps prevent accidental anchor deployment underway.
- Assists in breaking the anchor free during retrieval.
- Height Matched design for compatible Maxwell windlass installations.
- Manufactured from polished marine-grade stainless steel.
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Height Matched Chain Stopper |
| Material | Polished Stainless Steel |
| Application | Anchor Chain Load Transfer |
| Installation | Deck Mounted |
| Compatible Windlasses | Maxwell Height Matched Installations |
Available Variants
| Maxwell Part No. | Compatible Chain | Height (B) | Overall Width (F) | Mounting Thread (M) |
|---|---|---|---|---|
| P104358 (RC8/10) | RC8 / RC10 | 105 mm | 150 mm | M8 |
| P104359 (RC12) | RC12 | 127 mm | 182 mm | M10 |
Applications
- Relieves the windlass from continuous anchoring loads.
- Improves anchoring safety while the vessel is moored.
- Prevents unintended anchor deployment during navigation.
- Suitable for Maxwell RC-series windlass installations.
Maxwell Part Numbers: P104358, P104359
